EV Charging Modes

Mode 2 charging

Rated Voltage

AC 240V±10%

Rated Current

Max 16A 3.5KW~ /Max 32A 7.3KW~

Rated Frequency

50Hz

Over Voltage Category (OVC)

OVC III

Insulation Resistance

R > 1 MΩ

AC Withstand Voltage

1430V

Impulse Dielectric Withstand Voltage (1,2 μs/50 μs)(Uimp)

4kV

Protection Against Electric Shock

Class I

Electrical Life(contactcor)

100,000

Electrical Life(Interface)

100,000

Standby Power Consumption

<8W

Residual Current Protection

AC30mA+DC6mA

Streng

IK10

Universal Interface

T1:SAE J1772, T2:IEC/EN 62196-2, GB/T:20234.2-2015

Pollution Degree

PD 3

IP Protection Class

IP65

Altitude During Operation (m)

<2000m

Altitude Of Test Laboratory

<50m

Work Humidity

3%~95%

Operation Temperature

-25�? 40�?/p>

Colling

Natural Air Cooling

Mounting Method

Mounted on walls, poles or equivalent positions

Normal Environmental Conditions

Indoor use; Outdoor use

Status Indicating Led

LCD Display

Current Selection

3.6kW(6A/8A/10A/13A/16A) 7kW(6A/8A/10A/13A/16A/20A/25A/32A)

Charging Time Reservation

Free PE Connection

Over Temperature

Over/Under Voltage Protection

Over Current Protection
